Description

Polyphonic analog synth emulation with polyphonic arpeggiator and chord generator. Fixes Godel 2 bugs; adds 37 new oscillator types; improved 5D SV ffilter.

Features

Top-quality audio

* First audio instrument built entirely in gen~, for complete internal 64-bit operation

* Custom antialiasing and 3x oversampling

* More than 150 automation parameters

Modular modulation matrix

* Six assignable polyphonic modulations with individual level control for each matrix selection

* 21 sources, including envelopes, LFOs, gate levels, voice number, oscillator pitch, and external MIDI controllers

* 37 destinations, covering all main audio parameters.

Custom oscillators

* 2 complete oscillators with variable mix and ring modulation

* 37 oscillator waveforms, all with variable shape

Unique anti-aliasing with the newest technology

FM, sync, and FM feedback on all oscillators

* Graphical pitch tracking, graphical FM tracking, and wave display

12/24-dB/octave filter

* Variable mixing mixing of poles, saturation, and drive

* Graphical pitch tracking

* unfiltered oscillator mix with variable oversaturation

* table-based gain compensation across six dimensions

LFOs

* Two polyphonic LFOs with gate sync option

* Sine, pulse, saw/triangle, and S&H waveforms

* Adjustable waveform shape and frequency

* Polyphonic spread by frequency or amplitude

Envelopes

* Two ADSR envelopes, one with single, multi, and repeat modes

* Graphical gate velocity sensitivity

* Attack velocity sensitivity

* Pitch slope modulation

Stereo effects

* Phaser/flanger

* High-quality chorus

* Ping-pong tempo delay

* Efficient reverb

* Custom fast-response limiter

Keyboard

* Direct, stored note, and pitch transposition modes

* Multicolor display

* Notes may be stored in the preset and recalled in the same order played

* transpose, scale remap, mod wheel, and sprung pitch bend.

MIDI input

* Note on/off, program change, mod wheel, pitch bend, volume, all notes off, all sounds off, and MTC start/96-clock/stop signals

Arpeggiator

* Sequences notes in the order played, with adjustable rate

* The arpeggio may either adjust to the number of notes on, or with fixed note count, allowing new notes to substitute into the arpeggio

* Hold mode allows including multiple notes with the same pitch in the arpeggio

* Notes are stored in the sequence played

* Notes are fully polyphonic with adjustable duration (notes may overlap)

* Keyboard input in direct mode may play along with the arpeggio

* Adjustable rate, syncs with external clock

Chord generator

* May add chord notes to directly played notes or arpeggiated notes

* Adjustable velocity response and duration for each note in the chord adds realism

* Pitch remapping to different keys with sophisticated note cache system to track note-off events even when remapping is changed while a note is on, for either direct notes, stored notes, or both

* Arpeggiated chords may have variable and intervals and patterns

Auto Sequencer

* Simple way to build long song sequences with minimal effort

* Simply switches to next preset after the number of chosen bars, when enabled and clock is on

Custom voice allocator

* Optimally assigns notes for best quality when CPU resources are low, with complex note age adjustment both for note on and note-off events

Presets and preset bank management

* Loading and saving of external preset files

* Single-click recall, save, and delete of 128 programs

* Last session state restored when starting a new session

* Text comments stored with each preset

Open component design

You may find in-depth documentation on prototypes of the design internals on this site

There is no license. I simply request acknowledgment in using this for your music or own designs, out of common courtesy and in aspiration for something better.
