ESX8CV Track Helper Mac
Apple Silicon compatible Requires Expert Sleepers ES-...
- Type
- Audio Effect
- Author
- bhenry1790
- Version
- 1.0
- License
- None
- Live version
- 12.0.5
- Max version
- 8.6.2
- Downloads
- 116
- Updated
- No Updates
ESX8CV Track Helper Mac is an Audio Effect for Ableton Live by bhenry1790, distributed as freeware, with no license specified by the author. It targets Live 12.0.5 and Max 8.6.2. On maxforlive.com it has 116 downloads. Published 2024-06-28. 2 user comments below.
New to Max for Live? Read what Audio Effects do, how device licenses work, how to install a device.
Description
Apple Silicon compatible
Requires Expert Sleepers ES-5 & ESX-8CV expanders.
Use this device with standard Ableton CV Tools to send CV out via ESX-8CV.
Send output from Ableton CV Tools to Audio Tracks in Live, then use the ESX-8CV Track Helper to encode the signal for your ESX-8CV expander.
A little "plumbing" advice:
Create a group of 8 audio tracks. Set the new Audio Tracks to NO INPUT, set monitoring ON.
Drop the ESX8CV Track Helper on the group's master. Choose your ES-5 stereo pair, then your ESX-8CV header.
Choose your 8 audio tracks in the ESX-8CV Track Helper. Now any signal in your audio channels will output to the corresponding jacks!
Let me know if you have any troubles and I'll make a step-by-step video.
You'll need to add the es*encoder~ externals to Max for these to work.
https://www.expert-sleepers.co.uk/downloads.html
Mac location for externals:
Users/Shared/Max 8/Library/
Comments (2)
It requires an ES-5 and an ESX-8CV
The ES-5 is an expansion module for the Expert Sleepers ES-3 Lightpipe/CV Interface, ES-8 USB Audio Interface, ES-9 USB Audio Interface, or ES-10 ADAT Interface
The ESX-8CV is an expansion module for the ES-4, ES-40 or ES-5, adding eight CV outputs from one expansion header
